Last update: 5 June 2024

Standard sample
Name P/N Qty Remarks Applicable models
Standard sample for autotuning 400mL Nal (sodium iodide) 9030
Standard sample for autotuning 200mL PEG (polyethylene glycol), raffinose 8080
Standard sample for autotuning 200mL PEG (polyethylene glycol), PPG (polypropylene glycol), raffinose 8060
8050
8030
8040
Standard sample for autotuning 200mL PEG (polyethylene glycol), PPG (polypropylene glycol), raffinose 2020
Standard sample for autotuning 200mL PEG (polyethylene glycol), raffinose 2010
Drain tube, nebulizer gas tube
Name P/N Qty Remarks Applicable models
Silicone rubber tube for waste liquid 1m For waste liquid from the waste tray 8060
8050
8030
8040
2020
2010
PVC tube for waste liquid 1m For waste liquid from the spray section 9030
8060
8050
8030
8040
2020
2010
Rotary pump oil
Name P/N Qty Remarks Applicable models
Rotary pump oil  LV0700 1L 2 L per use 9030
8060
Rotary pump oil  Ultragrade#19 4L 1.5 L per use except 8080
except 8060
Rotary pump oil  GS495 1L 8080
Sample delivery unit (for LCMS-8080)
Name P/N Qty Remarks Applicable models
Syringe for autotuning 5mL Inner diameter: 10.30 mm LCMS-8080
PTFE tube 1m Cut the tube into 20 to 30 mm length pieces before use. LCMS-8080
PEEK nut 5 LCMS-8080
PEEK coupling 1 LCMS-8080
Tee joint 1 LCMS-8080
PEEK tube 3m Inner diameter: 0.13 mm LCMS-8080
Straight joint 1 LCMS-8080
Tube cutter 1 LCMS-8080
Syringe for infusion analysis 1mL Inner diameter: 4.61 mm LCMS-8080
Standard sample introduction unit (for LCMS-2010)
Name P/N Izgled Qty Remarks Applicable models
Plunger assembly 1 5mL LCMS-2010
Reflex fitting set Set of 5 Used for pipe connection from the 6-port valve to the ESI/APCI probe LCMS-2010
Microsyringe1005C 228-25237-07 1 LCMS-2010
